- Build/Test information:
- Build directory: Exec/hydro_tests/Sedov/
- Parallel run
- Files:
- Dimensionality: 2
- Compilation:
Successful
- Compilation time: 1.493 s
- Compilation command:
gmake -j20 AMREX_HOME=/raid/testing/castro-gfortran/AMReX/ MICROPHYSICS_HOME=/raid/testing/castro-gfortran/Microphysics/ DEBUG=FALSE USE_ACC=FALSE USE_MPI=FALSE USE_OMP=TRUE DIM=2 CASTRO_HOME=/raid/testing/castro-gfortran/Castro/ COMP=gnu TEST=TRUE
- make output
- Execution:
- Execution time: 19.035 s
- Execution command:
./Castro2d.gnu.TEST.OMP.ex inputs.2d.cyl_in_cartcoords.gammae amr.plot_file=Sedov-2d-tau_plt amr.check_file=Sedov-2d-tau_chk amr.checkpoint_files_output=0 amrex.fpe_trap_invalid=1 fab.format=NATIVE
- execution output
- execution stderr
- job_info
- Comparison:
- Analysis:
/raid/testing/castro-gfortran/AMReX/Tools/Plotfile//fcompare.gnu.ex -n 0 /raid/testing/castro-gfortran/Castro-SBU-amrex-benchmarks/Sedov-2d-tau_plt00159 Sedov-2d-tau_plt00159
| variable name | absolute error | relative error |
|---|
| | (||A - B||) | (||A - B||/||A||) |
|---|
| level = 0 |
| density | 0.002374901784 | 0.000702531586 |
| xmom | 0.002622771088 | 0.0006883347749 |
| ymom | 0.002622771057 | 0.0006883347659 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.002632486452 | 0.0004407696385 |
| rho_e | 0.001701124445 | 0.0004637626696 |
| Temp | 9.753685001e-09 | 0.005089813388 |
| rho_X | 0.002374901784 | 0.000702531586 |
| pressure | 0.0006804497779 | 0.0004637626696 |
| kineng | 0.001314697107 | 0.0005569497365 |
| soundspeed | 0.06163772864 | 0.004126977446 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.002273985211 | 0.001488443708 |
| entropy | 0.0 | 0.0 |
| magvort | 0.04902717315 | 0.007092752676 |
| divu | 0.01877630646 | 0.000759070103 |
| eint_E | 2.027416118 | 0.005089813388 |
| eint_e | 2.027416118 | 0.005089813388 |
| logden | 0.005788120333 | 0.002503390701 |
| StateErr | 0.002374901784 | 0.000702531586 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.001269534157 | 0.001064219103 |
| y_velocity | 0.001259413154 | 0.001055734922 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.001787030692 | 0.00148161721 |
| radvel | 0.001787030497 | 0.00148162344 |
| magmom | 0.002636900037 | 0.0006600607628 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 7.085897483e-05 | 0.003510408646 |
| level = 1 |
| density | 0.004923462287 | 0.001197438264 |
| xmom | 0.005792401456 | 0.001189082028 |
| ymom | 0.005792401453 | 0.001189082043 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.006822432653 | 0.0009196264413 |
| rho_e | 0.003283797197 | 0.0007757476788 |
| Temp | 2.132186356e-08 | 0.01110616978 |
| rho_X | 0.004923462287 | 0.001197438264 |
| pressure | 0.001313518879 | 0.0007757476788 |
| kineng | 0.003538635457 | 0.001110813165 |
| soundspeed | 0.1067040087 | 0.007137879494 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.003328119239 | 0.002021742725 |
| entropy | 0.0 | 0.0 |
| magvort | 0.1740278699 | 0.01343950566 |
| divu | 0.05834942813 | 0.001091606331 |
| eint_E | 4.431995686 | 0.01110616978 |
| eint_e | 4.431995686 | 0.01110616978 |
| logden | 0.007945950056 | 0.003435400555 |
| StateErr | 0.004923462287 | 0.001197438264 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.002321027205 | 0.001882186454 |
| y_velocity | 0.002382936571 | 0.001932390612 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.002029961213 | 0.001614725535 |
| radvel | 0.00202996091 | 0.001614725311 |
| magmom | 0.006110948516 | 0.001204845996 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0001114662477 | 0.003861992577 |
| level = 2 |
| density | 0.00949191324 | 0.002059560949 |
| xmom | 0.01064258584 | 0.001957095016 |
| ymom | 0.01064258585 | 0.001957095022 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.01152521067 | 0.001378515466 |
| rho_e | 0.005599878947 | 0.001226075205 |
| Temp | 2.987791369e-08 | 0.01553641179 |
| rho_X | 0.00949191324 | 0.002059560949 |
| pressure | 0.002239951579 | 0.001226075205 |
| kineng | 0.006450159626 | 0.001700419765 |
| soundspeed | 0.1426878465 | 0.0095368755 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.006406344912 | 0.003719743026 |
| entropy | 0.0 | 0.0 |
| magvort | 0.3899597722 | 0.02196860133 |
| divu | 0.1652455491 | 0.001564991428 |
| eint_E | 6.210469558 | 0.01553641179 |
| eint_e | 6.210469558 | 0.01553641179 |
| logden | 0.01264465063 | 0.005465176581 |
| StateErr | 0.00949191324 | 0.002059560949 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.002444286377 | 0.001930406146 |
| y_velocity | 0.00249742757 | 0.001972375079 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.002626205382 | 0.002043299091 |
| radvel | 0.002626205429 | 0.002043299204 |
| magmom | 0.01105053037 | 0.00186883694 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0001598708965 | 0.004940895929 |
| level = 3 |
| density | 0.01314514306 | 0.00280345034 |
| xmom | 0.01627926578 | 0.002910518684 |
| ymom | 0.01627926581 | 0.002910518699 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.02102658317 | 0.002439714705 |
| rho_e | 0.009390136967 | 0.002011607572 |
| Temp | 6.727583603e-08 | 0.03498264259 |
| rho_X | 0.01314514306 | 0.00280345034 |
| pressure | 0.003756054787 | 0.002011607572 |
| kineng | 0.01163644621 | 0.00294557536 |
| soundspeed | 0.328464388 | 0.02195350902 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.009370370562 | 0.005389829168 |
| entropy | 0.0 | 0.0 |
| magvort | 0.4837170842 | 0.02380142975 |
| divu | 0.7186530854 | 0.003968995455 |
| eint_E | 13.9840598 | 0.03498264259 |
| eint_e | 13.9840598 | 0.03498264259 |
| logden | 0.02391413832 | 0.01033597848 |
| StateErr | 0.01314514306 | 0.00280345034 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.004430541433 | 0.003473023216 |
| y_velocity | 0.004430541404 | 0.003473023197 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.004566331029 | 0.003515605847 |
| radvel | 0.004562408293 | 0.003512587425 |
| magmom | 0.01652663362 | 0.002715238999 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0002829213748 | 0.007938762058 |
