- Build/Test information:
- Build directory: Exec/hydro_tests/Sedov/
- Parallel run
- Files:
- Dimensionality: 2
- Compilation:
Successful
- Compilation time: 21.494 s
- Compilation command:
gmake -j20 AMREX_HOME=/raid/testing/castro-gfortran/AMReX/ MICROPHYSICS_HOME=/raid/testing/castro-gfortran/Microphysics/ DEBUG=FALSE USE_ACC=FALSE USE_MPI=FALSE USE_OMP=TRUE DIM=2 CASTRO_HOME=/raid/testing/castro-gfortran/Castro/ COMP=gnu TEST=TRUE
- make output
- Execution:
- Execution time: 5.542 s
- Execution command:
./Castro2d.gnu.TEST.OMP.ex inputs.2d.sph_in_cylcoords.testsuite amr.plot_file=Sedov-2d_plt amr.check_file=Sedov-2d_chk amr.checkpoint_files_output=0 fab.format=NATIVE
- execution output
- job_info
- Comparison:
- Analysis:
/raid/testing/castro-gfortran/AMReX/Tools/Plotfile//fcompare.gnu.ex -n 0 /raid/testing/castro-gfortran/Castro-SBU-amrex-benchmarks/Sedov-2d_plt00130 Sedov-2d_plt00130
| variable name | absolute error | relative error |
|---|
| | (||A - B||) | (||A - B||/||A||) |
|---|
| level = 0 |
| density | 0.01341478678 | 0.006336170022 |
| xmom | 0.06422537391 | 0.00856707853 |
| ymom | 0.0760760025 | 0.01059618776 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.5823448507 | 0.008564599857 |
| rho_e | 0.4184069873 | 0.008808230833 |
| Temp | 5.862625399e-06 | 0.06167266396 |
| rho_X | 0.01341478678 | 0.006336170022 |
| pressure | 0.1673627949 | 0.008808230833 |
| kineng | 0.1639378634 | 0.007999863128 |
| soundspeed | 4.064355998 | 0.0386376696 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.007164348458 | 0.00577181603 |
| entropy | 0.0 | 0.0 |
| magvort | 9.06980499 | 0.1283944481 |
| divu | 8.386320845 | 0.06343291337 |
| eint_E | 1218.614424 | 0.06167266396 |
| eint_e | 1218.614424 | 0.06167266396 |
| logden | 0.06968823804 | 0.02485746933 |
| StateErr_0 | 0.01341478678 | 0.006336170022 |
| StateErr_1 | 5.862625399e-06 | 0.06167266396 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.3398746157 | 0.07628977283 |
| y_velocity | 0.2714407123 | 0.06027152313 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.2986141551 | 0.0629070496 |
| radvel | 0.3649890606 | 0.07692615407 |
| magmom | 0.07733557248 | 0.008493290912 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0021648686 | 0.05732505543 |
| level = 1 |
| density | 0.0259491336 | 0.009387731537 |
| xmom | 0.0954444653 | 0.008140394083 |
| ymom | 0.1628855714 | 0.01365775443 |
| zmom | 0.0 | 0.0 |
| rho_E | 1.177285316 | 0.01309515174 |
| rho_e | 0.7519580239 | 0.01306298864 |
| Temp | 3.018240829e-05 | 0.313003558 |
| rho_X | 0.0259491336 | 0.009387731537 |
| pressure | 0.3007832096 | 0.01306298864 |
| kineng | 0.4471447131 | 0.01382706426 |
| soundspeed | 21.95152793 | 0.2071959914 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.02524268366 | 0.01770783621 |
| entropy | 0.0 | 0.0 |
| magvort | 57.37312987 | 0.2844729275 |
| divu | 15.74369533 | 0.08235439206 |
| eint_E | 6273.76228 | 0.313003558 |
| eint_e | 6273.76228 | 0.313003558 |
| logden | 0.2616274378 | 0.09311711194 |
| StateErr_0 | 0.0259491336 | 0.009387731537 |
| StateErr_1 | 3.018240829e-05 | 0.313003558 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.5272725373 | 0.1134786782 |
| y_velocity | 0.8833854646 | 0.1879768999 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.5313688491 | 0.1070329071 |
| radvel | 0.8718015099 | 0.1756339651 |
| magmom | 0.1628979586 | 0.01224803767 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.01216118421 | 0.1420220302 |
| level = 2 |
| density | 0.1483330464 | 0.04380327871 |
| xmom | 0.1829578465 | 0.01215747461 |
| ymom | 0.6633592069 | 0.04583814498 |
| zmom | 0.0 | 0.0 |
| rho_E | 2.640799561 | 0.02381548894 |
| rho_e | 1.768031143 | 0.02673139485 |
| Temp | 4.45485707e-05 | 0.4488546561 |
| rho_X | 0.1483330464 | 0.04380327871 |
| pressure | 0.7072124571 | 0.02673139485 |
| kineng | 1.458700976 | 0.03260018377 |
| soundspeed | 29.14180334 | 0.2711260863 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.05529369859 | 0.03557260654 |
| entropy | 0.0 | 0.0 |
| magvort | 137.8115559 | 0.4813917524 |
| divu | 31.68612449 | 0.07852198062 |
| eint_E | 9259.935117 | 0.4488546561 |
| eint_e | 9259.935117 | 0.4488546561 |
| logden | 0.3225514744 | 0.1142859249 |
| StateErr_0 | 0.1483330464 | 0.04380327871 |
| StateErr_1 | 4.45485707e-05 | 0.4488546561 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.6255724327 | 0.1236198999 |
| y_velocity | 1.275849639 | 0.2537671366 |
| z_velocity | 0.0 | 0.0 |
| magvel | 1.017551731 | 0.1966802269 |
| radvel | 1.271525748 | 0.2459145106 |
| magmom | 0.6624527108 | 0.03816166138 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.01582504436 | 0.1481846154 |
| level = 3 |
| density | 0.2486284677 | 0.07014430138 |
| xmom | 0.2627152544 | 0.01669258431 |
| ymom | 1.193716347 | 0.07816175545 |
| zmom | 0.0 | 0.0 |
| rho_E | 4.297390975 | 0.03645270215 |
| rho_e | 2.580202189 | 0.03747310758 |
| Temp | 5.644856622e-05 | 0.5682319887 |
| rho_X | 0.2486284677 | 0.07014430138 |
| pressure | 1.032080875 | 0.03747310758 |
| kineng | 2.835587245 | 0.05782813515 |
| soundspeed | 39.70607067 | 0.3692429354 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.1049677926 | 0.06581883357 |
| entropy | 0.0 | 0.0 |
| magvort | 164.8544111 | 0.4406106396 |
| divu | 29.85505069 | 0.0429800907 |
| eint_E | 11733.48668 | 0.5682319887 |
| eint_e | 11733.48668 | 0.5682319887 |
| logden | 0.4255329536 | 0.1507523961 |
| StateErr_0 | 0.2486284677 | 0.07014430138 |
| StateErr_1 | 5.644856622e-05 | 0.5682319887 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.7369630915 | 0.1445981398 |
| y_velocity | 1.534758045 | 0.2835373403 |
| z_velocity | 0.0 | 0.0 |
| magvel | 1.468968319 | 0.2713219386 |
| radvel | 1.529388026 | 0.2824927475 |
| magmom | 1.193783455 | 0.06431792457 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0247248347 | 0.1974568707 |
