- Build/Test information:
- Build directory: Exec/hydro_tests/Sedov/
- Parallel run
- Files:
- Dimensionality: 2
- Compilation:
Successful
- Compilation time: 21.625 s
- Compilation command:
gmake -j20 AMREX_HOME=/raid/testing/castro-gfortran/AMReX/ MICROPHYSICS_HOME=/raid/testing/castro-gfortran/Microphysics/ DEBUG=FALSE USE_ACC=FALSE USE_MPI=FALSE USE_OMP=TRUE DIM=2 CASTRO_HOME=/raid/testing/castro-gfortran/Castro/ COMP=gnu TEST=TRUE
- make output
- Execution:
- Execution time: 5.003 s
- Execution command:
./Castro2d.gnu.TEST.OMP.ex inputs.2d.sph_in_cylcoords.testsuite amr.plot_file=Sedov-2d_plt amr.check_file=Sedov-2d_chk amr.checkpoint_files_output=0 fab.format=NATIVE
- execution output
- job_info
- Comparison:
- Analysis:
/raid/testing/castro-gfortran/AMReX/Tools/Plotfile//fcompare.gnu.ex -n 0 /raid/testing/castro-gfortran/Castro-SBU-amrex-benchmarks/Sedov-2d_plt00130 Sedov-2d_plt00130
| variable name | absolute error | relative error |
|---|
| | (||A - B||) | (||A - B||/||A||) |
|---|
| level = 0 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.491090938e-05 | 0.9984278752 |
| rho_X | 1.11717595 | 0.5276727 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.491090938e-05 | 0.9984278752 |
| StateErr_2 | 635.0818228 | 635.0818228 |
| X(X) | 635.0818228 | 635.0818228 |
| abar | 1.11717595 | 1.11717595 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| level = 1 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.627885661e-05 | 0.9984499709 |
| rho_X | 1.764153779 | 0.6382256271 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.627885661e-05 | 0.9984499709 |
| StateErr_2 | 644.1491669 | 644.1491669 |
| X(X) | 644.1491669 | 644.1491669 |
| abar | 1.764153779 | 1.764153779 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| level = 2 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.91000146e-05 | 0.9984945033 |
| rho_X | 2.386345744 | 0.7046964263 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.91000146e-05 | 0.9984945033 |
| StateErr_2 | 663.2326218 | 663.2326218 |
| X(X) | 663.2326218 | 663.2326218 |
| abar | 2.386345744 | 2.386345744 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| level = 3 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.91912879e-05 | 0.998495915 |
| rho_X | 2.544528391 | 0.7178750204 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.91912879e-05 | 0.998495915 |
| StateErr_2 | 663.8560546 | 663.8560546 |
| X(X) | 663.8560546 | 663.8560546 |
| abar | 2.544528391 | 2.544528391 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
