- Build/Test information:
- Build directory: Exec/hydro_tests/Sedov/
- Parallel run
- Files:
- Dimensionality: 3
- Compilation:
Successful
- Compilation time: 29.878 s
- Compilation command:
gmake -j20 AMREX_HOME=/raid/testing/castro-gfortran/AMReX/ MICROPHYSICS_HOME=/raid/testing/castro-gfortran/Microphysics/ DEBUG=FALSE USE_ACC=FALSE USE_MPI=TRUE USE_OMP=FALSE DIM=3 CASTRO_HOME=/raid/testing/castro-gfortran/Castro/ COMP=gnu TEST=TRUE
- make output
- Execution:
- Execution time: 186.709 s
- Execution command:
mpiexec -n 16 ./Castro3d.gnu.TEST.MPI.ex inputs.3d.sph.testsuite amr.plot_file=Sedov-3d_plt amr.check_file=Sedov-3d_chk amr.checkpoint_files_output=0 fab.format=NATIVE
- execution output
- job_info
- Comparison:
- Analysis:
/raid/testing/castro-gfortran/AMReX/Tools/Plotfile//fcompare.gnu.ex -n 0 /raid/testing/castro-gfortran/Castro-SBU-amrex-benchmarks/Sedov-3d_plt00127 Sedov-3d_plt00127
| variable name | absolute error | relative error |
|---|
| | (||A - B||) | (||A - B||/||A||) |
|---|
| level = 0 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 8.985596897e-05 | 0.9983285531 |
| rho_X | 1.145557646 | 0.5339207028 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 8.985596897e-05 | 0.9983285531 |
| StateErr_2 | 597.2840236 | 597.2840236 |
| X(X) | 597.2840236 | 597.2840236 |
| abar | 1.145557646 | 1.145557646 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| level = 1 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.191604027e-05 | 0.9983658819 |
| rho_X | 1.885448052 | 0.6534333725 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.191604027e-05 | 0.9983658819 |
| StateErr_2 | 610.9508777 | 610.9508777 |
| X(X) | 610.9508777 | 610.9508777 |
| abar | 1.885448052 | 1.885448052 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| level = 2 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.283179541e-05 | 0.9983820257 |
| rho_X | 2.50449511 | 0.7146521913 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.283179541e-05 | 0.9983820257 |
| StateErr_2 | 617.0567916 | 617.0567916 |
| X(X) | 617.0567916 | 617.0567916 |
| abar | 2.50449511 | 2.50449511 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| level = 3 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 9.286859837e-05 | 0.998382678 |
| rho_X | 2.748540186 | 0.7332294839 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 9.286859837e-05 | 0.998382678 |
| StateErr_2 | 617.3060656 | 617.3060656 |
| X(X) | 617.3060656 | 617.3060656 |
| abar | 2.748540186 | 2.748540186 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
