- Build/Test information:
- Build directory: Exec/radiation_tests/RadSphere/
- Parallel run
- Files:
- Dimensionality: 1
- Compilation:
Successful
- Compilation time: 30.926 s
- Compilation command:
gmake -j30 AMREX_HOME=/raid/testing/castro-gfortran/amrex/ MICROPHYSICS_HOME=/raid/testing/castro-gfortran/Microphysics/ DEBUG=FALSE USE_ACC=FALSE USE_MPI=TRUE USE_OMP=FALSE DIM=1 CASTRO_HOME=/raid/testing/castro-gfortran/Castro/ NGROUPS=60 COMP=gnu TEST=TRUE TINY_PROFILE=TRUE
- make output
- Execution:
- Execution time: 314.421 s
- Execution command:
mpiexec -n 16 ./Castro1d.gnu.TEST.TPROF.MPI.ex inputs amr.plot_file=radsphere-1d_plt amr.check_file=radsphere-1d_chk amr.checkpoint_files_output=0 fab.format=NATIVE amrex.fpe_trap_invalid=1
- execution output
- job_info
- Comparison:
- Analysis:
/raid/testing/castro-gfortran/amrex/Tools/Plotfile//fcompare.gnu.ex --abort_if_not_all_found -n 0 /raid/testing/castro-gfortran/Castro-SBU-benchmarks/radsphere-1d_plt01001 radsphere-1d_plt01001
| variable name | absolute error | relative error |
|---|
| | (||A - B||) | (||A - B||/||A||) |
|---|
| level = 0 |
| density | 0.0 | 0.0 |
| xmom | 0.0 | 0.0 |
| ymom | 0.0 | 0.0 |
| zmom | 0.0 | 0.0 |
| rho_E | 0.0 | 0.0 |
| rho_e | 0.0 | 0.0 |
| Temp | 0.0 | 0.0 |
| rho_X | 0.0 | 0.0 |
| rad0 | 1.033697572e-09 | 2.535309112e-11 |
| rad1 | 2.017330303e-09 | 2.544963183e-11 |
| rad2 | 3.893461553e-09 | 2.527308143e-11 |
| rad3 | 7.579956218e-09 | 2.532767143e-11 |
| rad4 | 1.477053502e-08 | 2.54194821e-11 |
| rad5 | 2.8624072e-08 | 2.53885887e-11 |
| rad6 | 5.545871318e-08 | 2.537362346e-11 |
| rad7 | 1.073431122e-07 | 2.536029661e-11 |
| rad8 | 2.068818503e-07 | 2.527252844e-11 |
| rad9 | 4.002249625e-07 | 2.532225061e-11 |
| rad10 | 7.701382856e-07 | 2.529003976e-11 |
| rad11 | 1.479151251e-06 | 2.527671658e-11 |
| rad12 | 2.843604307e-06 | 2.537142756e-11 |
| rad13 | 5.409441656e-06 | 2.530529733e-11 |
| rad14 | 1.028750557e-05 | 2.536560232e-11 |
| rad15 | 1.933379099e-05 | 2.529470562e-11 |
| rad16 | 3.621354699e-05 | 2.535363527e-11 |
| rad17 | 6.684102118e-05 | 2.531288404e-11 |
| rad18 | 0.0001224186271 | 2.542219776e-11 |
| rad19 | 0.0002186782658 | 2.533751309e-11 |
| rad20 | 0.0003798343241 | 2.509538149e-11 |
| rad21 | 0.0006458573043 | 2.49881415e-11 |
| rad22 | 0.001044996083 | 2.440554506e-11 |
| rad23 | 0.001624941826 | 2.35539836e-11 |
| rad24 | 0.002318948507 | 2.095289708e-11 |
| rad25 | 0.003044456244 | 1.598539107e-11 |
| rad26 | 0.003486454487 | 8.682928408e-12 |
| rad27 | 0.003414571285 | 3.065442756e-12 |
| rad28 | 0.00267700851 | 7.207950864e-13 |
| rad29 | 0.001580938697 | 1.200370432e-13 |
| rad30 | 0.0006619207561 | 1.422546468e-14 |
| rad31 | 0.00017601531 | 1.11044885e-15 |
| rad32 | 2.670753747e-05 | 5.290592742e-17 |
| rad33 | 2.469867468e-06 | 1.711543539e-18 |
| rad34 | 0.0001248121262 | 3.511098596e-17 |
| rad35 | 0.004009246826 | 5.339424616e-16 |
| rad36 | 0.06213378906 | 4.374641502e-15 |
| rad37 | 0.3842773438 | 1.542408468e-14 |
| rad38 | 0.99609375 | 2.443612376e-14 |
| rad39 | 1.8671875 | 3.026224319e-14 |
| rad40 | 3.14453125 | 3.702393204e-14 |
| rad41 | 3.0234375 | 2.917349653e-14 |
| rad42 | 1.6484375 | 1.522395407e-14 |
| rad43 | 1.609375 | 1.737023037e-14 |
| rad44 | 1.0703125 | 1.741810265e-14 |
| rad45 | 0.43359375 | 1.467897215e-14 |
| rad46 | 0.1030273438 | 1.086402964e-14 |
| rad47 | 0.01379394531 | 7.502880971e-15 |
| rad48 | 0.001276016235 | 6.720293048e-15 |
| rad49 | 0.0001534819603 | 1.717653299e-14 |
| rad50 | 6.448477507e-06 | 4.089191437e-14 |
| rad51 | 6.629852578e-08 | 8.10259003e-14 |
| rad52 | 1.272155714e-10 | 1.381533256e-13 |
| rad53 | 3.080868893e-14 | 2.005517774e-13 |
| rad54 | 5.298191085e-19 | 2.245830972e-13 |
| rad55 | 3.190784589e-25 | 1.734927752e-13 |
| rad56 | 3.436581245e-33 | 9.898692432e-14 |
| rad57 | 3.22999296e-43 | 5.123556504e-14 |
| rad58 | 9.048762055e-56 | 2.60637873e-14 |
| rad59 | 1.754537822e-71 | 1.279443454e-14 |
| pressure | 0.0 | 0.0 |
| kineng | 0.0 | 0.0 |
| soundspeed | 0.0 | 0.0 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 0.0 | 0.0 |
| uplusc | 0.0 | 0.0 |
| uminusc | 0.0 | 0.0 |
| entropy | 0.0 | 0.0 |
| magvort | 0.0 | 0.0 |
| divu | 0.0 | 0.0 |
| eint_E | 0.0 | 0.0 |
| eint_e | 0.0 | 0.0 |
| logden | 0.0 | 0.0 |
| StateErr_0 | 0.0 | 0.0 |
| StateErr_1 | 0.0 | 0.0 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 0.0 | 0.0 |
| y_velocity | 0.0 | 0.0 |
| z_velocity | 0.0 | 0.0 |
| magvel | 0.0 | 0.0 |
| radvel | 0.0 | 0.0 |
| circvel | 0.0 | 0.0 |
| magmom | 0.0 | 0.0 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 0.0 | 0.0 |
| Ertot | 10.125 | 1.56534346e-14 |
| rad_analytic_0 | 0.0 | 0.0 |
| rad_analytic_1 | 0.0 | 0.0 |
| rad_analytic_2 | 0.0 | 0.0 |
| rad_analytic_3 | 0.0 | 0.0 |
| rad_analytic_4 | 0.0 | 0.0 |
| rad_analytic_5 | 0.0 | 0.0 |
| rad_analytic_6 | 0.0 | 0.0 |
| rad_analytic_7 | 0.0 | 0.0 |
| rad_analytic_8 | 0.0 | 0.0 |
| rad_analytic_9 | 0.0 | 0.0 |
| rad_analytic_10 | 0.0 | 0.0 |
| rad_analytic_11 | 0.0 | 0.0 |
| rad_analytic_12 | 0.0 | 0.0 |
| rad_analytic_13 | 0.0 | 0.0 |
| rad_analytic_14 | 0.0 | 0.0 |
| rad_analytic_15 | 0.0 | 0.0 |
| rad_analytic_16 | 0.0 | 0.0 |
| rad_analytic_17 | 0.0 | 0.0 |
| rad_analytic_18 | 0.0 | 0.0 |
| rad_analytic_19 | 0.0 | 0.0 |
| rad_analytic_20 | 0.0 | 0.0 |
| rad_analytic_21 | 0.0 | 0.0 |
| rad_analytic_22 | 0.0 | 0.0 |
| rad_analytic_23 | 0.0 | 0.0 |
| rad_analytic_24 | 0.0 | 0.0 |
| rad_analytic_25 | 0.0 | 0.0 |
| rad_analytic_26 | 0.0 | 0.0 |
| rad_analytic_27 | 0.0 | 0.0 |
| rad_analytic_28 | 0.0 | 0.0 |
| rad_analytic_29 | 0.0 | 0.0 |
| rad_analytic_30 | 0.0 | 0.0 |
| rad_analytic_31 | 0.0 | 0.0 |
| rad_analytic_32 | 0.0 | 0.0 |
| rad_analytic_33 | 0.0 | 0.0 |
| rad_analytic_34 | 0.0 | 0.0 |
| rad_analytic_35 | 0.0 | 0.0 |
| rad_analytic_36 | 0.0 | 0.0 |
| rad_analytic_37 | 0.0 | 0.0 |
| rad_analytic_38 | 0.0 | 0.0 |
| rad_analytic_39 | 0.0 | 0.0 |
| rad_analytic_40 | 0.0 | 0.0 |
| rad_analytic_41 | 0.0 | 0.0 |
| rad_analytic_42 | 0.0 | 0.0 |
| rad_analytic_43 | 0.0 | 0.0 |
| rad_analytic_44 | 0.0 | 0.0 |
| rad_analytic_45 | 0.0 | 0.0 |
| rad_analytic_46 | 0.0 | 0.0 |
| rad_analytic_47 | 0.0 | 0.0 |
| rad_analytic_48 | 0.0 | 0.0 |
| rad_analytic_49 | 0.0 | 0.0 |
| rad_analytic_50 | 0.0 | 0.0 |
| rad_analytic_51 | 0.0 | 0.0 |
| rad_analytic_52 | 0.0 | 0.0 |
| rad_analytic_53 | 0.0 | 0.0 |
| rad_analytic_54 | 0.0 | 0.0 |
| rad_analytic_55 | 0.0 | 0.0 |
| rad_analytic_56 | 0.0 | 0.0 |
| rad_analytic_57 | 0.0 | 0.0 |
| rad_analytic_58 | 0.0 | 0.0 |
| rad_analytic_59 | 0.0 | 0.0 |
