- Build/Test information:
- Build directory: Exec/hydro_tests/Sedov/
- Files:
- Dimensionality: 2
- Compilation:
Successful
- Compilation time: 89.680 s
- Compilation command:
gmake -j20 AMREX_HOME=/raid/testing/castro-gpu/amrex/ MICROPHYSICS_HOME=/raid/testing/castro-gpu/Microphysics/ DEBUG=FALSE USE_ACC=FALSE USE_MPI=FALSE USE_OMP=FALSE DIM=2 CASTRO_HOME=/raid/testing/castro-gpu/Castro/ COMP=gnu USE_CUDA=TRUE CUDA_ARCH=70 TINY_PROFILE=TRUE HYPRE_DIR=/opt/hypre/hypre-git-gpu
- make output
- Execution:
- Execution time: 13.819 s
- Execution command:
./Castro2d.gnu.TPROF.CUDA.ex inputs.2d.sph_in_cylcoords.testsuite amr.plot_file=Sedov-2d_plt amr.check_file=Sedov-2d_chk amr.checkpoint_files_output=0
- execution output
- job_info
- Comparison:
- Analysis:
/raid/testing/castro-gpu/amrex/Tools/Plotfile//fcompare.gnu.ex --abort_if_not_all_found -n 0 /raid/testing/castro-gpu/Castro-gpu-benchmarks/Sedov-2d_plt00130 Sedov-2d_plt00130
| variable name | absolute error | relative error |
|---|
| | (||A - B||) | (||A - B||/||A||) |
|---|
| level = 0 |
| density | 7.771561172e-15 | 3.670720506e-15 |
| xmom | 4.04121181e-14 | 5.390607609e-15 |
| ymom | 3.552713679e-14 | 4.948370047e-15 |
| zmom | 0.0 | 0.0 |
| rho_E | 2.611244554e-13 | 3.840381641e-15 |
| rho_e | 1.918465387e-13 | 4.038719831e-15 |
| Temp | 1.490777987e-19 | 1.568243638e-15 |
| rho_X | 7.771561172e-15 | 3.670720506e-15 |
| pressure | 7.638334409e-14 | 4.020022054e-15 |
| kineng | 1.10134124e-13 | 5.374340618e-15 |
| soundspeed | 9.947598301e-14 | 9.456652337e-16 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 5.662137426e-15 | 4.56158934e-15 |
| entropy | 4173512088.0 | 4173512088.0 |
| magvort | 3.339550858e-13 | 4.727552464e-15 |
| divu | 6.394884622e-13 | 4.836997889e-15 |
| eint_E | 2.546585165e-11 | 1.288797244e-15 |
| eint_e | 2.546585165e-11 | 1.288797244e-15 |
| logden | 3.774758284e-15 | 1.346438666e-15 |
| StateErr_0 | 7.771561172e-15 | 3.670720506e-15 |
| StateErr_1 | 1.490777987e-19 | 1.568243638e-15 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 1.953992523e-14 | 4.386018809e-15 |
| y_velocity | 1.643130076e-14 | 3.648456106e-15 |
| z_velocity | 0.0 | 0.0 |
| magvel | 2.087219286e-14 | 4.397005464e-15 |
| radvel | 2.109423747e-14 | 4.445882731e-15 |
| circvel | 1.130915023e-12 | 7.374111861e-13 |
| magmom | 4.263256415e-14 | 4.682072661e-15 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 5.06539255e-16 | 1.341300385e-14 |
| level = 1 |
| density | 1.643130076e-14 | 5.94442353e-15 |
| xmom | 9.059419881e-14 | 7.726718125e-15 |
| ymom | 9.059419881e-14 | 7.59621193e-15 |
| zmom | 0.0 | 0.0 |
| rho_E | 7.034373084e-13 | 7.824456965e-15 |
| rho_e | 3.87245791e-13 | 6.727220415e-15 |
| Temp | 8.605854744e-19 | 8.924613068e-15 |
| rho_X | 1.643130076e-14 | 5.94442353e-15 |
| pressure | 1.54543045e-13 | 6.71179101e-15 |
| kineng | 3.232969448e-13 | 9.997317424e-15 |
| soundspeed | 9.521272659e-13 | 8.986934914e-15 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 1.171285291e-14 | 8.21660976e-15 |
| entropy | 4173512088.0 | 4173512088.0 |
| magvort | 1.648459147e-12 | 8.173547451e-15 |
| divu | 2.053468506e-12 | 1.074157921e-14 |
| eint_E | 1.80079951e-10 | 8.984348283e-15 |
| eint_e | 1.80079951e-10 | 8.984348283e-15 |
| logden | 1.953992523e-14 | 6.954551175e-15 |
| StateErr_0 | 1.643130076e-14 | 5.94442353e-15 |
| StateErr_1 | 8.605854744e-19 | 8.924613068e-15 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 3.15303339e-14 | 6.785903609e-15 |
| y_velocity | 3.425038031e-14 | 7.288189097e-15 |
| z_velocity | 0.0 | 0.0 |
| magvel | 3.375077995e-14 | 6.798373863e-15 |
| radvel | 3.375077995e-14 | 6.799464372e-15 |
| circvel | 7.496208515e-13 | 5.079831364e-13 |
| magmom | 1.136868377e-13 | 8.547931986e-15 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 1.276756478e-15 | 1.49103528e-14 |
| level = 2 |
| density | 3.108624469e-14 | 9.179879149e-15 |
| xmom | 1.616484724e-13 | 1.074147535e-14 |
| ymom | 1.652011861e-13 | 1.141540788e-14 |
| zmom | 0.0 | 0.0 |
| rho_E | 1.364242053e-12 | 1.230312667e-14 |
| rho_e | 7.602807273e-13 | 1.149491308e-14 |
| Temp | 8.605854744e-18 | 8.670935815e-14 |
| rho_X | 3.108624469e-14 | 9.179879149e-15 |
| pressure | 3.037570195e-13 | 1.148148445e-14 |
| kineng | 6.039613254e-13 | 1.349779737e-14 |
| soundspeed | 4.774847184e-12 | 4.442366228e-14 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 1.948441408e-14 | 1.253508833e-14 |
| entropy | 4173512099.0 | 4173512099.0 |
| magvort | 5.499600775e-12 | 1.921074352e-14 |
| divu | 6.892264537e-12 | 1.707985028e-14 |
| eint_E | 1.789885573e-09 | 8.676070223e-14 |
| eint_e | 1.789885573e-09 | 8.676070223e-14 |
| logden | 4.04121181e-14 | 1.431875734e-14 |
| StateErr_0 | 3.108624469e-14 | 9.179879149e-15 |
| StateErr_1 | 8.605854744e-18 | 8.670935815e-14 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 5.062616992e-14 | 1.000428045e-14 |
| y_velocity | 4.352074257e-14 | 8.656297644e-15 |
| z_velocity | 0.0 | 0.0 |
| magvel | 5.462297281e-14 | 1.055794842e-14 |
| radvel | 5.462297281e-14 | 1.056414441e-14 |
| circvel | 3.590428125e-11 | 1.880029279e-11 |
| magmom | 2.202682481e-13 | 1.26889092e-14 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 2.123301535e-15 | 1.988244799e-14 |
| level = 3 |
| density | 4.04121181e-14 | 1.140126799e-14 |
| xmom | 2.220446049e-13 | 1.410842434e-14 |
| ymom | 2.238209618e-13 | 1.465527328e-14 |
| zmom | 0.0 | 0.0 |
| rho_E | 1.946887096e-12 | 1.651450749e-14 |
| rho_e | 1.094235813e-12 | 1.589193921e-14 |
| Temp | 3.987153489e-17 | 4.013615062e-13 |
| rho_X | 4.04121181e-14 | 1.140126799e-14 |
| pressure | 4.369837825e-13 | 1.586614061e-14 |
| kineng | 8.562039966e-13 | 1.746117335e-14 |
| soundspeed | 2.71143108e-11 | 2.521470279e-13 |
| Gamma_1 | 0.0 | 0.0 |
| MachNumber | 3.197442311e-14 | 2.004919014e-14 |
| entropy | 4173512125.0 | 4173512125.0 |
| magvort | 1.404032446e-11 | 3.752593759e-14 |
| divu | 1.605826583e-11 | 2.311788812e-14 |
| eint_E | 8.285496733e-09 | 4.012519395e-13 |
| eint_e | 8.287315723e-09 | 4.0134003e-13 |
| logden | 2.757793993e-13 | 9.769961387e-14 |
| StateErr_0 | 4.04121181e-14 | 1.140126799e-14 |
| StateErr_1 | 3.987153489e-17 | 4.013615062e-13 |
| StateErr_2 | 0.0 | 0.0 |
| X(X) | 0.0 | 0.0 |
| abar | 0.0 | 0.0 |
| x_velocity | 7.105427358e-14 | 1.394142516e-14 |
| y_velocity | 6.983302825e-14 | 1.290123298e-14 |
| z_velocity | 0.0 | 0.0 |
| magvel | 9.159339953e-14 | 1.69175185e-14 |
| radvel | 9.181544414e-14 | 1.695919978e-14 |
| circvel | 2.770475185e-11 | 1.36056819e-11 |
| magmom | 3.090860901e-13 | 1.665274866e-14 |
| angular_momentum_x | 0.0 | 0.0 |
| angular_momentum_y | 0.0 | 0.0 |
| angular_momentum_z | 3.386180225e-15 | 2.704262977e-14 |
